Taw qhia rau YKS-500 Series lub cev muaj zog

Lub YKs-500 Series cov motors yog feem ntau siv hauv cov roj thiab roj kev lag luam rau kev tsav tsheb high-fais fab, hnyav-ua haujlwm, xws li:

1.Txoj kev sib zog tiv thaiv: Tsav dej cov twj tua cov twj, compressors, thiab roj hloov twj.

2.nnuralg thauj mus los: compressor drives rau cov raj xa hluav taws xob betting.

HV hluav taws xob lub cev muaj zog yog cov motors high-voltage tshwj xeeb tsim los ntawm Simo Tsav rau cov roj thiab roj appSs. Lawv muaj kev ua haujlwm txuag hluav taws xob, kev ua haujlwm siab, thiab kev sib kho yooj yim thiab kev saib xyuas, tshuaj thauj cov nroj tsuag, thiab tshuab hydraulic nyob hauv Suav teb.

Qauv Tus lej piav qhia

Simo Yks Series High-Volfage Peb-theem Asynchronous Tsav Qauv Qauv Piav Qhia

Kev nojYks5006-4Ua piv txwv:

"Yks": Muab cov nas khi-tawb-tawb rotor asynchronous tsavNrog cua-rau-dej txias.

"5006" : Ncej nruab nrab qhov siab=500lub hli; "6" qhia txog tusThawj Cov Hlau Tseem Ceeb.

"4" : Tus naj npawb ntawm cov ncej (4-ncej lub cev muaj zog).

Ntsiab lus tseem ceeb

Thav duab loj:355-630 (6KV); 400-800 (10KV) (Customizable)
Cov Ntsuas Hluav Taws Xob:6KV / 10KV (Customizable)
Cov zaus ntsuas:50HZ
Ceev:3000rpm, 1500rpm, 1000RPM, 750RPM
Lub Zog Muaj Zog:220-3150kw
Hom Mounting:Imb3
Kev Tiv Thaiv Chav Kawm:IP44 / IP54
Cua txias txoj kev:IC81W
Rwb Thaiv Tsev Kawm:F
Ambient kub:Caij ntuj hloov pauv, max. 40 degree; min . -15 degree
Vaum noo:Max . 90% txheeb ze cov av noo hauv lub hli wettest, nrog qhov tsawg dua ib hlis tsawg dua lossis sib npaug rau 25 degree.

Qhov tseem ceeb ntawmHV hluav taws xob tsav

1. Lub zog txuag hluav taws xob:Sib ntsibIE3 cov qauv kev pab tau zoo, zoo tagnrho rau lub zog-txuag retrofits.
2. Dav pom tseeb ntxiv:IP54 / IP55 Kev Tiv Thaiv, Tsim nyog rau noo, plua plav, lossis ib puag ncig kub.
3. Kev ntseeg siab:Hwm cov ntaub ntawv rwb thaiv tsev kom uaKev ua haujlwm ntev ua lag luam.

Cov Ntawv Qhia Cov Ntawv

HV-6KV TSAV RAU COV ROJ & CUA
Ntaus	Rated zog (kw)	Rated tam sim no (a)	Kev ceev (R / min)	Kev ua tau zoo (%)	Lub Hwj Chim Factor (COS φ)	Max. Torque / rated torque	Xauv Torque / Rated Torque	Xauv Tam Sim No / Rated Tam Sim No	J (TSAV) (KG.M²)	J (LOAD) (KG.M²)	Y huab hwm coj (kg)	Yks Pawg (kg)	Lub sij hawm lub sijhawm (h)
Y.yks5001-2	1120	128.2	2975	95.5	0.88	1.8	0.6	7	14.5	58	4480	5319	500
Y.yks5002-2	1250	143	2975	95.6	0.88	1.8	0.6	7	15.7	67	4600	5452	500
Y.yks5003-2	1400	160	2980	95.7	0.88	1.8	0.6	7	16.9	73	4770	5629	500
Y.yks5004-2	1600	182.6	2980	95.8	0.88	1.8	0.6	7	18.8	80	4970	5830	500
Y.yks5006-4	1000	116	1485	95.3	0.87	1.8	0.7	6.5	27.5	217	3960	4396	1000
Y.yks5007-4	1120	128.4	1485	95.4	0.88	1.8	0.7	6.5	30	238	4110	4603	1000
Y.yks5009-4	1250	143.1	1485	95.5	0.88	1.8	0.7	6.5	35	259	4420	4950	1000
Y.yks50010-4	1400	160.1	1485	95.6	0.88	1.8	0.7	6.5	37.8	284	4580	5129	1000
Y.yks5006-6	710	84.6	990	95	0.85	1.8	0.7	6	39	598	3860	3246	2000
Y.yks5007-6	800	95.2	990	95.1	0.85	1.8	0.7	6	42.8	664	4010	4411	2000
Y.yks5009-6	900	107	990	95.2	0.85	1.8	0.7	6	50	735	4280	4751	2000
Y.yks50010-6	1000	118.8	990	95.3	0.85	1.8	0.7	6	53.5	804	4430	4921	2000
Y.yks5005-8	500	63	740	94.3	0.81	1.8	0.8	5.5	36.3	893	3740	4300	2000
Y.yks5007-8	560	69.6	740	94.4	0.82	1.8	0.8	5.5	42.8	988	3990	4540	2000
Y.yks5008-8	630	78.2	740	94.5	0.82	1.8	0.8	5.5	46	1100	4140	4690	2000
Y.yks50010-8	710	88.1	740	94.6	0.82	1.8	0.8	5.5	53.5	1220	4420	4970	2000
Y.yks5005-10	400	51.6	590	93.3	0.8	1.8	0.8	5.5	47.3	1260	3660	4099	3000
Y.yks5006-10	450	58	590	93.4	0.8	1.8	0.8	5.5	52	1400	3770	4222	3000
Y.yks5007-10	500	64.3	590	93.6	0.8	1.8	0.8	5.5	55.5	1540	3900	4368	3000
Y.yks5008-10	560	71.9	590	93.7	0.8	1.8	0.8	5.5	60.3	1710	4030	4514	3000
Y.yks50010-10	630	80.8	590	93.8	0.8	1.8	0.8	5.5	69.8	1900	4270	4782	3000
Y.yks5006-12	280	39.3	495	92.7	0.74	1.8	0.8	5.5	50.8	1420	3720	4129	3000
Y.yks5007-12	315	43.6	495	92.8	0.75	1.8	0.8	5.5	55.5	1580	3860	4285	3000
Y.yks5008-12	355	49	495	93	0.75	1.8	0.8	5.5	60	1760	3990	4429	3000
Y.yks5009-12	400	55	495	93.3	0.75	1.8	0.8	5.5	65	1970	4140	4595	3000
Y.yks50010001010-12	450	61.8	495	93.4	0.75	1.8	0.8	5.5	69.8	2190	4290	4805	3000

10KV HV tsav rau cov roj & roj
Ntaus	Rated zog (kw)	Rated tam sim no (a)	Kev ceev (R / min)	Kev ua tau zoo (%)	Lub Hwj Chim Factor (COS φ)	Max. Torque / rated torque	Xauv Torque / Rated Torque	Xauv Tam Sim No / Rated Tam Sim No	J (lub cev muaj zog) (KGB M²)	J (LOAD) (KGB M²)	Y huab hwm coj (kg)	Yks Pawg (kg)	Lub sij hawm lub sijhawm (h)
Y.yks5001-2	710	49.2	2975	94.7	0.88	1.8	0.6	7	12.3	43	3850	5320	500
Y.yks5002-2	800	55.4	2975	94.8	0.88	1.8	0.6	7	13.3	51	4740	5420	500
Y.yks5003-2	900	62.2	2970	94.9	0.88	1.8	0.6	7	14.3	55	4070	5540	500
Y.yks5004-2	1000	69.1	2970	95	0.88	1.8	0.6	7	15.5	57	4200	5010	500
Y.yks5005-2	1120	77.2	2970	95.2	0.88	1.8	0.6	7	17	58	4350	5690	500
Y.yks5001-4	710	49.6	1490	95	0.87	1.8	0.7	7	30.5	85	3900	4290	1000
Y.yks5002-4	800	55.8	1490	95.1	0.87	1.8	0.7	7	32	92	4000	4400	1000
Y.yks5003-4	900	62	1490	95.2	0.88	1.8	0.7	7	33.8	100	4070	4477	1000
Y.yks5004-4	1000	68.8	1490	95.3	0.88	1.8	0.7	7	35	115	4270	4697	1000
Y.yks5005-4	1120	77	1490	95.4	0.88	1.8	0.7	7	38	130	4370	4807	1000
Y.yks5001-6	500	37	990	93.9	0.83	1.8	0.7	6	35.5	252	3830	4460	2000
Y.yks5002-6	560	40.9	990	94.1	0.84	1.8	0.7	6	37	285	3950	4580	2000
Y.yks5003-6	630	45.9	990	94.4	0.84	1.8	0.7	6	39	317	4040	4670	2000
Y.yks5004-6	710	51.6	990	94.6	0.84	1.8	0.7	6	40	341	4150	4780	2000
Y.yks5005-6	800	58.1	990	94.7	0.84	1.8	0.7	6	44	374	4150	4880	2000
Y.yks500-8c	220	18.4	740	92.1	0.75	1.8	0.7	6	36	690	3280	3630	2000
Y.yks500-8b	250	20.6	740	92.3	0.76	1.8	0.7	6	38	710	3390	3740	2000
Y.yks500-8a	280	22.7	740	92.5	0.77	1.8	0.7	6	40	730	3490	3840	2000
Y.yks5001-8	315	25.4	740	92.8	0.77	1.8	0.7	6	42	765	3740	4090	2000
Y.yks5002-8	355	28.6	740	93.1	0.77	1.8	0.7	6	45.5	795	3890	4240	2000
Y.yks5003-8	400	31.8	740	93.2	0.78	1.8	0.7	6	48	835	4040	4390	2000
Y.yks5004-8	450	35.7	740	93.4	0.78	1.8	0.7	6	50	930	4190	4540	2000
Y.yks5005-8	500	39	740	93.8	0.79	1.8	0.7	6	53	1010	4340	4670	2000
Y.yks5006-8	560	43.6	740	93.9	0.79	1.8	0.7	6	54.5	1025	4490	4840	2000
Y.yks5001-10	220	19	595	91.8	0.73	1.8	0.7	5.5	45.5	877	3800	4142	3000
Y.yks5002-10	250	21.4	595	92.2	0.73	1.8	0.7	5.5	49	910	3900	4251	3000
Y.yks5003-10	280	23.6	595	92.4	0.74	1.8	0.7	5.5	50	937	4250	4633	3000
Y.yks5004-10	315	26.5	595	92.6	0.74	1.8	0.7	5.5	53	1015	4450	4851	3000
Y.yks5005-10	355	29.4	595	92.8	0.75	1.8	0.7	5.5	57	1150	4650	5069	3000
Y.yks5006-10	400	33.1	595	93	0.75	1.8	0.7	5.5	59	1225	4850	5287	3000
Y.yks5004-12	220	19.5	495	91.7	0.71	1.8	0.7	5.5	56	1350	4100	4469	3000
Y.yks5005-12	250	22.2	495	91.9	0.71	1.8	0.7	5.5	57	1722	4200	4578	3000
Y.yks5006-12	280	22.4	495	92.1	0.72	1.8	0.7	5.5	59	1870	4400	4796	3000

Teeb Meem Teeb Duab

HV Motor for Oil & Gas

HV Electric Motor4

Chaw tsim tshuaj paus

HV Electric Motor5

Xi'anSimo TsavCo., Ltd. (yav tas los Xi'an Simo Tsav Hoobkas) yog cov kws tshaj lij kev lag luam ntawm hluav taws xob tshuab hluav taws xob hauv Suav kev lag luam.

Lub tuam txhab tau tsim nyob rau xyoo 1955 thiab muaj keeb kwm 70 xyoo hauv kev tsim khoom thiab muag khoom.

Nyob rau hauv 2017, nws dhau Iso 9001 - 2015 Kev Tswj Xyuas Kev Tswj Xyuas Zoo ntawm Tuam Txhab Nyiaj Txiag Zoo (CQC). Nws kuj tau muaj ntawv pov thawj xws li EU "CE", Australian "Gems", Neeg Kaus Lim ", Suav" CCC ", thiab lub zog - txuag cov ntawv pov thawj.

Cov khoom lag luam tseem ceeb muaj xws li YX, Yxkk, Yxks series siab - ua hauj lwm siab - voltage motors; Yr, yrkk, yrks kiav txhab siab - voltage motors; Ye3 High - efficiency, ye4, ye5 ultra - High - Effecticial series asynchronous motors; YVFE2, YVFE3, YVFE4, YVFE4, YVFE4, YVFE5 Series Siab Zoo Tshaj - Tshaj Ceev - Tswj Motors; YBX3, YBX4, YBK3, YBK3, YBLP Series Tas Tawg tawg - Pes Pov Thawj Kub - thiab qis - hluav taws xob asynchronous motors; T, td, tk, tdmk series synchronous motors; thiab z2, z4, z series dc motors. Cov khoom no tau siv dav hauv cov liaj teb xws li kev tiv thaiv ib puag ncig, kev thauj khoom, kev thauj khoom, kev thauj khoom, kev thauj khoom, kev thauj khoom, thiab siab - thev naus laus zis. Nws yog ib lub cev muaj zog txhawb cov chaw tsim tshuaj paus rau Tuam Tshoj cov tuam txhab Corporway Corporation thiab cov khoom lag luam tsim nyog rau cov hluav taws xob dav dav (ge).

Xaiv HV hluav taws xob lub cev muaj zog, xaiv Simo, xaiv zoo! Hu rau email: sales@simo-motor.com.cn
